X-axis drive motor: 85 series hybrid two-phase stepper motor 57NM
Y-axis drive motor: 85 series hybrid two-phase stepper motor 85NM
Z-axis drive motor: 85 series hybrid two-phase stepper motor 57NM
Under the gun way: three-axis motion
Ventilation mode: Axial blower duct
Maximum speed: 500mm / s
Effective working area: X * Y980 * 550MM
Maximum lifting range: Z axis 70mm

Suitable for shoes, belts, handbags, wallets and other materials fit; applicability glue are: white glue, water-based glue, pressure Pomerania glue, glue, oil-based plastic; spray speed, save labor and improve efficiency.
Glue with less low cost, the system is stable. Plastic spray head can be self-regulation, the user can adjust the different spray width according to their production needs, can be sprayed 5-20mm glue along the edge of the material, coating evenly.
Uniform and thin glue, glue dry, adhesive workers fast, high efficiency. Hand, foot and automatic control system, the touch screen can be set and stored rules and how irregular pattern 999.
Energy saving, ventilation systems can effectively be carried out when the glue smell glue suction process.
